Industrial Air Cooled Chiller Manufacturers in Pune

Overview of the Industrial Air Cooled Chiller: Specifications, Types, Applications, and How It Works

An Industrial Air Cooled Chiller removes excess heat from manufacturing equipment by circulating refrigerant through a finned‑tube condenser that uses fans to expel heat into the surrounding air.

• Key specifications include:
  1. Cooling Capacity: 1 ton to 200 ton (3.5 kW to 700 kW)
  2. Power Supply: 415 V / 50 Hz, 3-phase
  3. Compressor Types: Scroll, Screw, or Copeland brands
  4. Refrigerant: R134a or R410A
• There are three main types:
  1. Small‑Scale Chillers (1–10 TR): Ideal for laboratory equipment, small machining tools, and server‑room cooling.
  2. Medium‑Scale Chillers (10–50 TR): Suited for injection‑moulding machines, packaging lines, and medium production floors.
  3. Large‑Scale Chillers (50–200 TR): Designed for heavy manufacturing, large cold‑storage units, and data centers.

These chillers are widely applied in automotive, food & beverage, pharmaceuticals, plastics, textiles, and electronics industries. By moving heat away from critical processes, they help maintain precise temperature control and consistent product quality.

What Is an Industrial Air Cooled Chiller?

An Industrial Air Cooled Chiller is a refrigeration unit that absorbs process heat via an evaporator and rejects it to the atmosphere through an air‑cooled condenser. Unlike water‑cooled systems, it requires no cooling tower or large water supply, making it ideal where water is scarce or costly. Quality standards such as IS 9876 and CE certification guarantee safe, efficient operation.

Specification of the Industrial Air Cooled Chiller

Types of the Industrial Air Cooled Chiller

1. Portable Scroll‑Compressor Chiller: This compact model uses a scroll compressor for quiet operation. It features casters for easy relocation and quick hook‑up to existing piping.
2. Floor‑Mounted Screw‑Compressor Chiller: Built for continuous heavy loads, the screw compressor delivers high capacity with low power consumption. Its robust frame supports large industrial installations.
3. Glycol‑Compatible Process Chiller: For corrosion resistance and sub‑zero setpoints, this variant circulates a water‑glycol mix. It protects components in food, chemical, and pharmaceutical applications.

Applications of the Industrial Air Cooled Chiller

• Automotive Manufacturing: Regulates die‑cast molds and laser‑welding equipment to maintain tight tolerances and reduce scrap.
• Food & Beverage Processing: Controls fermentation temperatures, cooling conveyors, and cold‑storage rooms to ensure consistent product quality.
• Plastic Extrusion & Injection Molding: Stabilizes melt temperatures and mold surfaces, minimizing cycle times and part warpage.
• Textile Dyeing & Finishing: Maintains bath temperatures in dyeing machines, improving color consistency and fabric strength.
• Electronics Assembly: Keeps soldering and reflow ovens at precise temperatures to reduce defects.

How It Works

First, the compressor pressurizes refrigerant vapor. Next, the hot vapor flows through the air‑cooled condenser, where fans blow ambient air across fins to remove heat. The condensed liquid then passes through an expansion valve, dropping its pressure and temperature. Finally, the cold refrigerant enters the evaporator, absorbing heat from process fluid before returning to the compressor. This continuous cycle achieves stable cooling with high energy efficiency.

Industrial Air Cooled Chiller Ordering, Compliance, and Safety Information

When placing an order, specify your required cooling load, inlet/outlet sizes, and control preferences (e.g., remote monitoring). All ThermoChill chillers comply with:

• IS 9876 for industrial refrigeration safety
• CE marking for European markets
• RoHS directives on refrigerant environmental impact

Safety features include high‑pressure cut‑outs, low‑oil alarms, and phase‑failure protection. Recommended maintenance intervals are every six months for filter cleaning and annual refrigerant-level checks.

Why Choose Us?

1. Energy Efficiency: Our chillers achieve COPs above 4.0, reducing electricity costs by up to 20%.
2. Custom Design: We adapt each unit’s capacity, footprint, and controls to your facility’s needs.
3. Local Service: With a Pune-based support team, we guarantee a 24‑hour response for troubleshooting and spare parts.
4. Proven Reliability: Over 300 installations since 2012 demonstrate our commitment to durable, low‑maintenance systems.

Because of these factors, ThermoChill Technology stands out among Industrial Air Cooled Chiller Manufacturers in Pune and leading Industrial Air Cooled Chiller Suppliers in Pune.

Get Industrial Air Cooled Chiller in India | ThermoChill Technology

ThermoChill Technology is your go‑to Industrial Air Cooled Chiller Manufacturers in Pune, Industrial Air Cooled Chiller Suppliers in Pune, and Industrial Air Cooled Chiller Dealers in Pune. We combine in‑house R&D, rigorous testing, and skilled craftsmanship to deliver chillers that last.

Ready to improve your process cooling? Contact Us now for a personalized quote, on‑site evaluation, or technical consultation. Let us help you achieve peak efficiency and reliability!
